V2-L LED Controller 12-36V DC, 2x8A HS082970 9990001082970
Prece tiek piegādāta no Lietuvas noliktavas.
V2-L controller 12-48V DC 2x 8A, for dual color LED strips, 2 channel
Features:
Supports lighting systems: dual color WW/CW.
4096 levels 0-100% dimming smoothly without any flash. Compatible with dimmable LED strips/bulbs.
3 levels color temperature (warm/neutral/cool white light).
Simultaneous auto-transmission: automatically transmits the signal to another controller within 30m, synchronizes the operation with other controllers (it is recommended not to exceed 25 controllers connected to a push switch).
Match button for connecting remote controls.
Can be controlled by 2.4 GHz RF remote controls, push switches, sensor switches.
Control with the SkySmart smart app is supported.
One controller can control up to 10 remote controls. One remote control can control an unlimited number of controllers within 30 m.
Controller adopts the most advanced PWM (Pulse Width Modulation) digital control technology, it is used for controlling constant voltage LED lamps.
Features Push-dimm function.
Overload and short circuit protection.
Certificates: CE (EMC/LVD), RoHS.
Technical data:
Product model: V2-L.
Compatibility: Skydance R1, R6-1, RT1, RU4, R6, RA1, RT6, RS1, RS6, R11; R15, R16, R8-1, R9, RT4, R8, RT9, RS3, RS4, RS8, R21, R22; T1, T1-1, T1-K, KV, KC; T3, T3-1, T3-K.
Number of channels: 2.
Controlled lighting systems: CCT.
Operating frequency: RF 2.4GHz.
Supply voltage: 12V-48V DC.
Output voltage: 12V-48V DC.
Output current: 8A per channel.
Output power: (96-384)W per channel.
PWM frequency: 2000 Hz.
Grayscale: 4096 levels.
Dimming range: 0-100%.
Operating distance: up to 30m.
Safety class: IP20 (not waterproof).
Certificates: CE, EMC, LVD, RED, RoHS.
Operating temperature: -30~+55°C.
Dimensions: 175 x 45 x 27 mm.
Color: white.
Weight: 107g.
Warranty: 24 months.
